Features
1. Pneumatic unwinding, maximum diameter 800mm
2. Automatic YD-90 control unit with U-shaped photoelectric tracking
3. Magnetic powder 5NM drive
4. Automatic tool setting system, circular knife slitting
5. Optional slip axis for rewinding and pneumatic expansion axis for unwinding
6. Three-motor synchronous system for tension control, slitting speed 100-400 meters per minute
7. 3kW variable frequency motor drive for traction
8. Back-reel rewinding, maximum Ø800mm
9. PLC touchscreen display, full tension control system
10. Pneumatic clamping tension system
11. Manual or automatic unloading
12. Counting and parking
Main technical parameters
| 型 号 | Type | MFFQ-1100-1600 |
| 最大宽度 | Maximum Width | 1100-1300-1600mm |
| 放卷直径 | Unwinding Diameter | 最大Max￠800mm or ￠1200mm |
| 材料厚度 | Material Thickness | 20μm-200μm |
| 收卷直径 | Winding Diameter | 最大Max￠600mm |
| 收卷宽度 | Winding Width | 最小Min ￠30mm |
| 分切速度 | Cutting Speed | 最大Max500m/min（伺服） 最大Max300m/min（变频） |
